Description

Classification: Built ABS 1992- Lockheed USA /Rebuilt 2015 - Middle East. Cargo Deck Area: 236 m2. Containers: 28 containers of 20 ft (2 layers). Main Engine Port Side and Stbd Side: Cummins maker / Model KTA 50 M. Fuel (cargo): 332.45 m3. Fresh water: 17.41 m3. Fuel (ship): 16.72 m3. Berth: 18 nos’ (Central A/C comply to MLC 2006 T3). Maximum Speed: 12 kts MCR. Service Speed: 10 kts MCR.

Specifications

Accommodation

Water maker UV Sterilizer

Construction

Length B.P: 47.55m
Depth: 3.5m
GRT: 1087 MT
NRT: 512 MT
Cargo Deck Area: 236 m2
Hydraulic Rampage Migrigger

Equipment

Bow thruster
Make: Cummins / Model NT 855-M
Running Hours: 937
Power: 300 hp @ 1800 rpm
Date of Manufacture: May -90
Aft Anchor

Bow thruster hydraulic pump
Make: School
Model: SPJ 57

Engine(s)

Main Engine Port Side: Cummins maker / Model KTA 50 M
Running hours: 167.4
Power: 1250 hp @ 1800 rpm
Containers: 28 containers of 20 ft (2 layers)
Service Speed: 10 kts MCR

Storage Capacities
Fuel (cargo): 332.45 m3
Fresh water: 17.41 m3
Fuel (ship): 16.72 m3

Sewage holding tank pump
Make: Cutler Hammer
Type: Sewage Exfer pump

Sewage treatment pump
Make: ORCA II A Control
Type: ENVROVAC INC.,

Oil water separator
Type: VGC
Max. Pressure: 55
Max. Design Pressure: 100

Main generator engine (port)
Make: Cummins / Model - NTA855
Running Hours: 1209
Power: 250 KW

Main generator engine (stbd)
Make: Cummins/ Model - NTA855
Running Hours: 8154
Power: 250 KW

Electronics

Navtex Receiver: Furuno make / Navtex NX 700 model
Navigation system: MX Marine Make / MX 420 model
Radar (2EA): Raytheon Make /upto96NM range
Echo Sounder: Skipper Make / GDS101 model
Speed Log: Skipper Make / KLM224 model
FWD winch (2EA): Tulso winch make / Oklahoma Model
3 No’s VHF DSC
2 No’s MF/HF (with DSC)
3 No’s GPS System
2 No’s Inmarsat C
EPIRB, SART, Gyrocompass, Mgt. compass, AIS, Autopilot, GS pump (Electric Motor) 250
gpm,40 hp

Safety Equipment

Rescue Boat: Envirude Make / Engine power - 40 hp

EMERGENCY FIRE PUMP
Make: cummins
Model: BS500 part 99/ NEMAMG1/22
Power: 40 KW
Running hours: 8023 hrs

Disclaimer

The particulars and specifications are supplied by the vendor and not SeaBoats. Such information has not been verified and may be incorrect. Please do not rely on particulars and specifications unless you have verified their accuracy.
